To Set up Measurement Parameters
Press key to enter the Measurement Menu for setting to set up the
measurement parameters. Users may use the factory defaults or establish desired
configurations.
The Measurement parameters Menu includes: Conti, Filter, Res, Null, and Ratio. To
change these parameters, satisfy the dissimilar condition of the measurement
request.
Table 2- 1 Menu Description
Function
Menu
Description
Conti
Set up the resistance value in continuity test.
Filter
Choose the AC filter bandwidth.
Res
Choose the DC voltage input impedance.
Null
Set up null value.
Ratio
Measured the ratio of two DC voltage signal.
Freq
Measured the frequency of AC signal.
Save all changes, and end the current operation.
