User‟s Guide for DM3000 Series
1-17
Figure 1- 22 4-Wire Resistance Measurement
6. Use history function.
Press History, the menu shows as below:
Figure 1- 23 The History Data
Use the history function to review or save the data that has acquired by the current
measurement function. The data can be display “Info” (information), “List” and
“HistoG” formats.
Press Update softkey to update the History data.
Press Save softkey to save data.
NOTE
When measuring resistances, avoid contacting both ends of the resistor for accurate
measurement.
4-Wire Sense HI
Resistance
4-Wire Sense LO
