User‟s Guide for DM3000 Series
Figure 1- 25 Capacitance Measurement
6． Use history function.
Press History, the menu shows as below:
Figure 1- 26 The History Data
Use the history function to review or save the data that has acquired by the current
measurement function. The data can be display “Info” (information), “List” and
“HistoG” formats.
Press Update softkey to update the History data.
Press Save softkey to save data.
NOTE
Before measuring the electrolytic capacitance, you should make the two legs of the
electrolytic capacitance short circuit and let it be discharged, and then you can
measure it.
