User‟s Guide for DM3000 Series
2-15
1. Statistic Measurement
The Statistic function is for DC voltage, AC voltage, DC current, AC current,
resistance, frequency/period, and capacitance measurement.
The front panel can display the statistical data for any set of readings: average (Ave),
maximum (Max), minimum (Min), and which can read with All function and the
number of samples taken (Total).
Figure 2- 13
Press  Stats, the display shows:
Figure 2- 14
Table 2- 11 Statistic Measurement Menu Function Description
Function Menu
Description
Max (Maximum)
Maximum value from a set of measurements.
Min (Minimum)
Statistical measurement all reading Min value.
Ave (Average)
Statistical measurement all reading Average value.
All
The complete a set of measurement.
Save all changes, back to a higher level menu.
