To Measure Resistance
The multimeter provides 2-wire and 4-wire resistance measurement modes which
are introduced separately in the following part.
2-Wire Resistance Measurement
Operating Steps:
1. Press
and select 2-Wire Resistance Measurement Mode to enter following
interface.
Figure 2-17 2-Wire Resistance Measurement Interface
2. Connect the red lead to terminal Input-HI and black lead to terminal Input-LO
as the figure below.
Figure 2-18 Sketch map for connecting
