Rigol DM3058E User Manual

RIGOL
User’s Guide for DM3058/DM3058E
VI
DM3058/DM3058E Overview
RIGOL DM3058/DM3058E is a 5½ dual-display instrument especially designed for
high-precision, multifunction, and automation measurements. It realized a
combination of basic measurement functions and math functions as well as sensor
measurement function.
The DM3058/DM3058E holds a 256 x 64 lattice high-resolution monochrome LCD
display screen with clear keyboard layout and operation hints to make it easier and
agility to use. Besides, it supports multi-interface such as RS-232, USB, LAN (only
for DM3058) and GPIB (only for DM3058).
Main Features:
 Real 5½ digits resolution.
 Three measurement speeds: 2.5 reading/s, 20 reading/s and 123 reading/s.
 Double Display function enables to display two types of characteristic for one
signal synchronously.
 Two operation modes: Preset and Ordinary. Preset mode is able to store
configuration quickly.
 DC Voltage Range between 200mV and 1000V.
 DC Current Range between 200μA and 10A.
 True-RMS, AC Voltage Range between 200mV and 750V.
 True-RMS, AC Voltage Current between 20mA and 10A.
 Resistance Range between 200Ω and 100MΩ for 2&4-Wire Resistance
Measurement.
 Capacitance Range between 2nF and 10000μF.
 Frequency Range between 20Hz and 1MHz.
 Continuity and Diode Test.
 Sensor Measurement function, Built-in Thermocouple compensate in Cold
Terminal.
 Abundant Math operations: Max, Min, Average, P/F, dBm, dB, Relative
Measurement, Standard Deviation and Histogram.
 Support the storage of data and configuration via USB flash device.
 Support USB, GPIB (only for DM3058), RS-232 and LAN (only for DM3058)
interfaces. Support USB-TMC, IEEE 488.2 standard, LXI-C class standard (only
for DM3058) and SCPI language.
 In possession of compatible commands with both Agilent 34401A and Fluke
w ww. . com
information@itm.com1.800.561.8187

Rigol DM3058E Specifications

General

Backlight	Yes
Product type	Digital multimeter
Frequency range	0.02 - 1000 kHz
AC current range	0.02 - 10 A
AC voltage range	0.2 - 750 V
DC current range	0.0002 - 10 A
DC voltage range	0.2 - 1000 V
Resistance range	200 - 10000000 Ω
Capacitance range	2 - 10000000 nF
Measuring category	CAT III 300V
Basic accuracy (frequency)	0.01 + 0.003
Basic accuracy (DC current)	0.055 + 0.005
Basic accuracy (DC voltage)	0.015 + 0.003
Basic accuracy (resistance)	0.020 + 0.003
Basic accuracy (capacitance)	1 + 0.5
Display digits	5.5 digits
Display size (HxV)	256 x 64 mm
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	107 mm
Width	231.6 mm
Height	290.5 mm
Weight	2500 g
