Rigol DP832 User Manual

RIGOL Chapter 2 Front Panel Operations
2-64 DP800 User’s Guide
Delayer
Channel
CH1
Delayer On/off Off
Output Groups 1
Delay Parameter
State: Off, On alternately
Cycles 1
End State Outp Off
State Generation 0 1Patt
Time Generation FixTime
Fixed Time On Delay: 1s; Off Delay: 1s
Increase/Decline Time Base: 1s; Step: 1s
Stop Condition None
Recorder
Recorder Switch Off
Record Period 1s
Destination C:\REC 10:RIGOL.ROF
Analyzer
Channel CH1
Analysis Object
Voltage
Display Curve
Current Time
1s
Start Time 1s
End Time 2s
Number of Groups
0
Median 0V
Mode 0V
Average
0V
Variance 0V
Range 0V
Maximum 0V
Minimum 0V
Mean Deviation
0V
Monitor
Channel
CH1
Monitor Switch Off
Monitor Condition
>Volt
Voltage
Half of the rated value of CH1 (for DP811, it is half of the rated
value of Range1)
Current Half of the rated value of CH1 (for DP811, it is half of the rated
value of Range1)
Power The product of the two values above
Stop Mode
Output Off, Warning, Beeper
Trigger
Trig In
Trigger Input
Data Line
D0
Source under Control CH1
Trigger Type Rise Edge

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
