Rigol DP832 User Manual

Chapter 2 Front Panel Operations RIGOL
DP800 User’s Guide 2-57
To Set the GPIB Address
Before using the GPIB interface, use the USB to GPIB interface converter (option) to
extend a GPIB interface and then use a GPIB cable to connect the instrument and
PC.
Press Utility  I/O Config  GPIB and use the numeric keyboard or the left/right
direction key and knob to set the desired GPIB address. It can be any integer from 0
to 30. The default is 2. This setting is stored in the non-volatile memory and will not
be affected by factory reset.
System Setting
Power-on Setting
Select the instrument configuration ("Default" or "Last") the instrument uses at
power-on and the default is "Default".
 Last: use the system configuration before the last power-off.
 Default: use the factory setting (except those parameters that are not affected
by factory reset). For the details, refer to
 Table 2-2.
Press Utility  System  Power On to select the desired configuration type. This
setting is stored in the non-volatile memory and will not be affected by factory reset.
Over-temperature Protection
Press Utility  System  OTP to enable or disable the over-temperature
protection (OTP) function. When the OTP function is enabled, the instrument turns
off the output automatically when the temperature inside the instrument reaches the
limit.
Beeper
Press Utility  System  Beeper to enable or disable the beeper. When the
beeper is enabled, the instrument generates prompt sound during front panel
operation or when error occurs during remote operation.

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
