Rigol DP832 User Manual

RIGOL Chapter 1 Quick Start
1-4 DP800 User’s Guide
Front Panel
This section introduces the front panel of DP800 series by taking DP832 (as shown in
the figure below) as an example. The differences of different models are introduced
separately.
Figure 1-3 DP832 Front Panel
1 2 3 4
11 10 9 8 7 6 5

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
