Chapter 2 Front Panel Operations RIGOL
DP800 User’s Guide 2-61
Preset Setting
Press Utility  Preset to define the setting recalled by Preset at the front panel.
Pressing Preset can restore the instrument to factory setting or recall the
user-defined settings.
To Restore to Factory Setting
Press Utility  Preset to enter the interface as shown in the figure below. Press
Preset Key to select "Default" or any of the 4 groups of user-defined settings and
by default, "Default" is selected. When "Default" is selected, pressing Preset at the
front panel will restore the instrument to factory setting as shown in Table 2-2 on the
next page.
Figure 2-15 Preset Value Type Selecting Interface

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
