Rigol DP832 User Manual

RIGOL Chapter 2 Front Panel Operations
2-50 DP800 User’s Guide
Copy and Paste
You can only copy the files in C disk and paste the files to D disk.
1. Press Store  Browser to move the cursor to the directory area and select C
disk; press Browser again to switch to the file area and select the file to be
copied.
2. Press Copy and the instrument copies the file currently selected.
3. Press Browser to switch to the directory area and select D disk.
4. Press Paste, the instrument pastes the file copied to the D disk and the
corresponding prompt message is displayed when the file is successfully pasted.

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
