Rigol DP832 User Manual

RIGOL
DP800 User’s Guide XIII
Document Overview
Chapter 1 Quick Start
Introduce the appearance and dimensions, front panel, rear panel as well as user
interface of DP800. In addition, it provides the detailed procedures of power
connection, power-on inspection and fuse replacement as well as the method of rack
mount installation of DP800.
Chapter 2 Front Panel Operations
Introduce the function and operation method of each key at the front panel of DP800
in detail.
Chapter 3 Remote Control
Introduce how to realize the remote control of the instrument.
Chapter 4 Troubleshooting
Introduce the possible failures and their solutions when using DP800.
Chapter 5 Specifications
List the specifications of DP800.
Chapter 6 Appendix
Provide the accessory and option list as well as the warranty information of DP800.
Index
Provide keyword search to quickly locate the desired information.
Tip
For the newest version of this manual, download it from RIGOL official website
(
www.rigol.com).

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
