Rigol DP832 User Manual

RIGOL Chapter 5 Specifications
5-4 DP800 User’s Guide
Mechanical
Dimensions 239mm(W) x 157mm(H) x 418mm(D)
Weight
DP832: 10.5kg
DP831: 9.75kg
DP821: 10.0kg
DP811: 10.3kg
Power
AC Input
(50Hz-60Hz)
100Vac±10%, 115Vac±10%, 230Vac±10% (maximum 250Vac)
Maximum Power
DP832: 521VA
DP831: 416VA
DP821: 450VA
DP811: 503VA
I/O
USB Device 1
USB Host 1
LAN 1 (Option)
RS232 1 (Option)
Digital IO 1 (Option)
USB-GPIB
1 (Option, extend a GPIB interface using the USB-GPIB interface
converter)
Rear Output Interface 1 (only for DP811)
Environment
Cooling Method Fan Cooling
Working Temperature
0℃ to 40℃
Storage Temperature -40℃ to 70℃
Humidity 5% to 80% relative humidity
Altitude Below 1500m
Note
[1]
: The accuracy param eters are acquired via calibration under 25℃ after 1-hour warm-up.
Note
[2]
: The maximum time required for the output to change accordingly after receiving the
APPLy and SOURce commands.
Note
[3]
: The variation of the output within 8 hours after 30-minute warm-up when the load circuit
and environment temperature are constant.

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
