Rigol DP832 User Manual

RIGOL Chapter 2 Front Panel Operations
2-44 DP800 User’s Guide
4. Save the settings
Press Save  OK to save the start-up interface settings.
5. Select the start-up interface
Press Boot UI to select the default start-up interface or the user-defined
start-up interface.

Rigol DP832 Specifications

General

Number of Outputs	3
Output Voltage Range CH1/CH2	0-30V
Output Voltage Range CH3	0-5V
Output Current Range CH1/CH2	0-3A
Output Current Range CH3	0-3A
Total Power	195 W
Power per Channel CH1/CH2	90 W
Power per Channel CH3	15 W
Voltage Resolution	1 mV
Current Resolution	1 mA
Interfaces	USB, RS232
Display	3.5 inch TFT LCD
