RIGOL Chapter 14 Store and Recall
14-8 MSO1000Z/DS1000Z User’s Guide
English Input Method
For example, create a file or folder with the name “Filename”.
1. Press Keyboard.
1) Use to select English input method “En” and uppercase input state “A
a
”.
2) Use to input the letter “F”. If the input is wrong, press Delete to delete
the character input.
3) Use
to select lowercase input state “a
A
”.
4) Use
to input the remaining letters “ilename”.
2. During the name input, you can press Name to select the “Name Input Area”
and use to move the cursor, then press Delete to delete the characters at
the left of the cursor one by one.
3. After finishing the input, press OK and the oscilloscope will create a folder or a
specified type of file with this name under the current directory.
Name Input Area Keyboard Upper-lower Case Switch Input Method Switch
