RIGOL Chapter 1 Quick Start
1-22 MSO1000Z/DS1000Z User’s Guide
19. Source1 Waveform
Display the type of waveform currently set for Source1.
When the modulation of source1 is enabled,
will be displayed below the
Source1 waveform.
When the impedance of source1 is set to 50 Ω,
will be displayed below
the Source1 waveform.
This function is only applicable to MSO1000Z-S and DS1000Z-S models
oscilloscopes.
20. Source2 Waveform
Display the type of waveform currently set for Source2.
When the modulation of source2 is enabled,
will be displayed below the
Source2 waveform.
When the impedance of source2 is set to 50 Ω,
will be displayed below
the Source2 waveform.
This function is only applicable to MSO1000Z-S and DS1000Z-S models
oscilloscopes.
21. Notification Area
Display the sound icon and USB storage device icon.
Sound Icon: Press Utility Sound to enable or disable the sound. When
the sound is enabled, will be displayed; when the sound is disabled,
will be displayed.
USB Storage Device Icon: when a USB storage device is detected,
will
be displayed.
22. Operation Menu
Press any softkey to activate the corresponding menu. The following symbols
might be displayed in the menu:
Denote that the multifunction knob can be used to modify the
parameters. The backlight of turns on in the parameter modification
Denote that you can use to select the desired items and the item
currently selected is displayed in blue. Press down to enter the menu
bar corresponding to the selected item. The backlight of
is constant
on after menus with this symbol are selected.
Denote that you can press to open the pop-up numeric keyboard
and input the desired paramrter values directly. The backlight of is
constant on after menus with this symbol are selected.
Denote that the current menu has several options.
Denote that the current menu has a lower level menu.
Press this key to return to the previous menu.
The number of dots indicates the number of pages of the current menu.
