Chapter 1 Quick Start RIGOL
MSO1000Z/DS1000Z User’s Guide 1-21
level value will change with the up and down of .
Note: In slope trigger, runt trigger and window trigger, two trigger level labels
(
and ) are displayed.
12. CH1 Vertical Scale
Display the voltage value per grid of CH1 waveform vertically.
Press CH1 to select CH1, and use VERTICAL
SCALE to modify this
parameter.
The following labels will be displayed according to the current channel
setting: channel coupling (e.g.
) and bandwidth limit (e.g. ).
13. Analog Channel Label/Waveform
Different channels are marked with different colors and the colors of the channel
label and waveform are the same.
14. CH2 Vertical Scale
Display the voltage value per grid of CH2 waveform vertically.
Press CH2 to select CH2, and use VERTICAL
SCALE to modify this
parameter.
The following labels will be displayed according to the current channel
setting: channel coupling (e.g.
) and bandwidth limit (e.g. ).
15. CH3 Vertical Scale
Display the voltage value per grid of CH3 waveform vertically.
Press CH3 to select CH3, and use VERTICAL
SCALE to modify this
parameter.
The following labels will be displayed according to the current channel
setting: channel coupling (e.g.
) and bandwidth limit (e.g. ).
16. CH4 Vertical Scale
Display the voltage value per grid of CH4 waveform vertically.
Press CH4 to select CH4, and use VERTICAL
SCALE to modify this
parameter.
The following labels will be displayed according to the current channel
setting: channel coupling (e.g.
) and bandwidth limit (e.g. ).
17. Message Box
Display the prompt messages.
18. Digital Channel Status Area
Display the current status of the 16 digital channels. The digital channels
currently turned on are displayed in green and the digital channel currently
selected is displayed in red. The digital channels turned off are displayed in grey.
Note: This function is only applicable to MSO1000Z-S and MSO1000Z models
oscilloscopes.
