7
Table 4. MTSP Comfort Schedule Example (2 zone system example is shown)
ZONE A
Living
Time
Heat° Cool°
Time
Heat° Cool°
Time
Heat° Cool°
Time
Heat° Cool°
Time
Heat° Cool°
Mon - Fri 7.00 19 24 8.00 -- 28 5.00 21 24 10.30 -- --
Sat - Sun 8.00 20 24 8.00 21 24 6.00 21 24 11.00 -- --
ZONE B
Sleeping
Time
Heat° Cool°
Time
Heat° Cool°
Time
Heat° Cool°
Time
Heat° Cool°
Time
Heat° Cool°
Mon - Fri 6.00 19 24 8.00 -- 28 6.00 21 24 8.30 -- --
Sat - Sun 8.00 20 24 9.00 18 24 6.00 21 24 9.00 -- --
Sleep
Wake
Leave
Return
Pre-Sleep
Sleep
Wake
Leave
Return
Pre-Sleep (Optional)
Table 5. STSP Comfort Schedule Example (2 zone system example is shown)
Time
Heat° Cool°
Time
Heat° Cool°
Time
Heat° Cool°
Time
Heat° Cool°
Time
Heat° Cool°
Mon - Fri 7.00 20 24 8.00 -- 28 5.00 21 24 11.00 -- --
Zone A
ON ON OFF ON ON ON OFF OFF
Zone B
ON ON OFF OFF OFF OFF OFF OFF
Time
Heat° Cool°
Time
Heat° Cool°
Time
Heat° Cool°
Time
Heat° Cool°
Time
Heat° Cool°
Sat - Sun 6.00 20 24 9.00 20 24 6.00 21 24 11.00 -- --
Zone A
ON ON ON ON ON ON OFF OFF
Zone B
OFF OFF OFF OFF ON ON OFF OFF
Sleep
Wake
Leave
Return
Pre-Sleep (Optional)
Sleep
Wake
Leave
Return
Pre-Sleep (Optional)
Note: “- -” in the temperature location indicates the zone has
been set to “OFF”
