GAS PRESSURE SETTING
The regulator is electronically controlled and factory pre-set. Under normal circumstances it DOES NOT require
adjustment during installation. Make adjustments ONLY if the unit is not operating correctly and all other possible
causes for incorrect operation have been eliminated. Instructions for gas pressure setting are located in the
instruction pocket inside the appliance front cover.
NOTE
For all injector size and gas pressure values refer to the appliance data plate, located on the left
hand side of the water heater.
WIRING DIAGRAM
The wiring diagram is located in the instruction pocket inside the appliance front cover.
COMMISSIONING CHECK LIST
A commissioning check list is provided on the appliance front cover to enable the installer to step through the
correct commissioning procedure when installing a Rinnai gas continuous ow water heater.
The check list can also assist the installer to identify potential installation errors that may prevent the appliance
from operating correctly.
INSTALLATION RECORD
The Installation Record is a reference for the end user, help line sta󰀨 and service technicians. Ensuring that this
information is available here will be helpful in the event that a service enquiry is required.
Installer Details
Installation Company Name:
Address:
Telephone / Mobile Phone: /
Email:
Certicate of Compliance / Certication No.:
Authorised Persons - Licence No.:
Installers Name:
Installers Signature:
Installation Date:
System Details
Water Heater - Model Number *: REU-
Water Heater - Serial Number *:
* This information will need to be copied from the data plate, located on the left hand side of appliance.
Installation Address:
COMMISSIONING
