Rinnai INFINITY 26 - Specifications

Rinnai 32 HW_CF OIM
TABLE 1. APPLIANCE DIMENSIONS
Use this table in conjunction with
"Diagram 1. Dimensions" below.
All dimensions in mm
unless otherwise stated.
Model
REU-AM1220WD
Innity 12
REU-AM1620WD
Innity 16
REU-AM2024WD
Innity 20
REU-AM2626WD
Innity 26
REU-AM2626WDL
Innity 26 Touch
REU-E1620W
Innity Enviro 16
REU-E2626W
Innity Enviro 26
REU-A1620WB
B16
REU-A2024WB
B20
REU-A2626WB
B26
MC-601Q
Universal
A Width 356 356 356 356 356 351 351 351 351 351 90
B Depth 202 202 202 202 202 220 220 195 195 195 21
C Height Unit 503 503 503 503 503 531 531 531 531 531 120
D Height Including Brackets 571 571 571 571 571 565 565 571 571 571 -
E Hot Water outlet (from wall) 87 87 87 87 87 103 103 87 87 87 -
F Hot Water outlet (from centre) 105 105 105 105 105 127 127 105 105 105 -
G Cold Water inlet (from wall) 68 68 68 68 68 63 63 68 68 68 -
H Cold Water inlet (from centre) 10 10 10 10 10 20 20 10 10 10 -
I Gas Connection (from wall) 77 77 77 77 77 61 61 77 77 77 -
J Gas Connection (from centre) 83 83 83 83 83 83 83 83 83 83 -
K Neutraliser outlet (from wall) - - - - - 137 137 - - - -
L Neutraliser outlet (from centre) - - - - - 7* 7* - - - -
M
Gas Connection Length (from base) 40 40 40 40 40 38 38 40 40 40 -
Cold Connection Length (from base) 50 50 50 50 50 50 50 50 50 50 -
Hot Connection Length (from base) 39 39 41 41 41 39 41 39 41 41 -
Condensate outlet (from base) - - - - - 36 36 - - - -
* Measurement is from the left of the centre line
N Vertical Mounting Hole Centres - - - - - - - - - - 84
O
Cable Access Hole Size - - - - - - - - - - Ø20
Position - - - - - - - - - - Centre
