Rinnai 34 HW_CF OIM
TABLE 2. SUPPLY, FLOW RATES, WEIGHTS & SERVICE CONNECTIONS
Model
Gas Rate
Water
Supply
Pressure
Max Flow at Temp Rise
(at minimum water supply pressure)
Weight
Fittings
Min Max Hot Cold Gas Cond.
MJ/hr kPa L/min / °C kg (DN = mm)
REU-AM1220WD -
Innity 12 92 120 1000 15 / 20 12 / 25 7.5 / 40 6 / 50 13.5 R ½ (15) R ½ (15) R ¾ (20) -
REU-AM1620WD -
Innity 16 124 120 1000 20 / 20 16 / 25 10 / 40 8 / 50 13.5 R ½ (15) R ½ (15) R ¾ (20) -
REU-AM2024WD -
Innity 20 156 160 1000 24 / 20 20 / 25 12.5 / 40 10 / 50 14.5 R ¾ (20) R ¾ (20) R ¾ (20) -
REU-AM2626WD -
Innity 26 199 200 1000 26 / 20 26 / 25 16.3 / 40 13 / 50 15.5 R ¾ (20) R ¾ (20) R ¾ (20) -
REU-AM2626WDL -
Innity 26 Touch 199 200 1000 26 / 20 26 / 25 16.3 / 40 13 / 50 15.5 R ¾ (20) R ¾ (20) R ¾ (20) -
REU-E1620W -
Innity Enviro 16 110 140 1000 20 / 20 16 / 25 10 / 40 8 / 50 16 R ½ (15) R ½ (15) R ¾ (20) R ½ (15)
REU-E2626W -
Innity Enviro 26 175 220 1000 26 / 20 26 / 25 16.3 / 40 13 / 50 18 R ¾ (20) R ¾ (20) R ¾ (20) R ½ (15)
REU-A1620WB -
B16 124 120 1000 20 / 20 16 / 25 10 / 40 8 / 50 13 R ½ (15) R ½ (15) R ¾ (20) -
REU-A2024WB -
B20 156 160 1000 24 / 20 20 / 25 12.5 / 40 10 / 50 14 R ¾ (20) R ¾ (20) R ¾ (20) -
REU-A2626WB -
B26 199 200 1000 26 / 20 26 / 25 16.3 / 40 13 / 50 15 R ¾ (20) R ¾ (20) R ¾ (20) -
TABLE 3. MAXIMUM DELIVERY TEMPERATURES
(a) Factory "Pre-Set" Maximum delivery temperature (°C)
(b) Can the Factory "Pre-Set" Maximum delivery temperature be changed by an authorised person?
Delivery Temperature
Non - 50°C Compliant - Models 50°C Compliant - Models
REU-AM1220WD REU-AM1620WD REU-AM2024WD REU-AM2626WD
REU-AM2626WDL
REU-E1620W REU-E2626W
REU-A1620WB REU-A2024WB REU-A2626WB
REU-AM1220WD-50 REU-AM1620WD-50 REU-AM2024WD-50 REU-AM2626WD-50
REU-AM2626WDL-50
REU-E1620W-50 REU-E2626W-50
REU-A1620WB-50 REU-A2024WB-50 REU-A2626WB-50
(a) 60 60 60 60 60 60 60 60 60 60 50 50 50 50 50 50 50 50 50 50
(b) Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No No No No No No No No No No
TABLE 4. OTHER ACCESSORIES
Where the accessory compatibility information is not specied, please contact Rinnai for details about our full
accessory range and their model suitability, or visit: www.rinnai.com.au.
Pipe Cover
Pipe covers attach easily to a Rinnai gas continuous ow
water heater and are designed to conceal pipes and valves.
Pipe covers may also be joined to one another to conceal
longer pipe work.
REU Series Pipe Cover
REU-AM PCD01
REU-E PCD08
REU-A PC11D
Security Cage
Protects the Rinnai gas continuous ow water heater from
theft and damage.
All Models
CAGE01
Security Bracket
Prevent theft of your Rinnai gas continuous ow water
heater by securing it with the custom security bracket.
All Models
SECBKT
Sideways Flue
Diverter
Designed to redirect ue products when a Rinnai gas
continuous ow water heater is installed on a balcony.
* SFD-01 = RUE-A2626 / SFD-02 = REU-A1620 / SFD-03 = REU-A2024
REU Series Diverter
REU-AM SFD-01
REU-E SFD-04
REU-A SFD-01/02/03 *
Smart Box (plastic) *
Recess Box (metal) *
Recess boxes are available in either plastic or metal, and are designed to permit a recessed
installation of a Rinnai gas continuous ow water heater into a wall cavity, saving precious space.
Recess boxes are also suitable for painting. * Not Available REU-E1620W & REU-E2626W.
Water Controllers
An extended range of Deluxe Kitchen, Deluxe Bathroom and Wireless water controllers are also
available.
SPECIFICATIONS
