RKC INSTRUMENT CB100 Initial Setting Manual

2. SETTING
IMCB04-E10 11
(5) SL6 (Control action type selection)
Conduct setting so as to meet the instrument specification. An incorrect setting may
cause a malfunction.
When control action is of the type D or F, Control action type selection (Cool-side)
setting is ignored.
Factory set value varies depending on the instrument specification.
Set value Descri
p
tion
0
Direct action
(
D t
yp
e
)
1
Reverse action (F, A and W type)
Direct/reverse action
selection
0 PID action with autotuning (D, F type)
1
1 Heat/Cool PID action with autotuning (A, W type)
2
Control action type
selection
0 Heat-side time proportioning output (M, V, G, T output)
3, 4
1
Heat-side continuous output (Current output: 4 to 20 mA DC)
Control output type
selection (Heat-side)
0 Cool-side time proportioning output (M, V, T output)
3
1
Cool-side continuous output (Current output: 4 to 20 mA DC)
Control output type
selection (Cool-side)
1
D type: PID action with autotuning (Direct action)
F type: PID action with autotuning (Reverse action)
2
A type: Heat/cool PID action with autotuning (Air cooling)
W type: Heat/cool PID action with autotuning (Water cooling)
3
M output: Relay contact output G output: Trigger output for triac driving
V output: Voltage pulse output T output: Triac output
4
The G output cannot be selected in the heat/cool control.
