RNA ESK 2001 - Connection Diagram

Rhein-Nadel Automation GmbH 22
VT-BA-ESK2001_EN_2023.docxVT-BA-ESK2001_EN_2023.docx
8. Connection diagram
Supply connection230V, 50/60Hz
Drive 1
max. 10A
Drive 2
max. 4A
Orienting air
External setpoint
Control-circuit fuse
Ext. enable 2
Ext. enable 1
ready
active
wire bridge
not applicable for 50/60 Hz
required for 100/120 Hz
Bowl feeder
capacitor motor
Y adapter
accumulation
