• All specifications relate to installed condition ready for operation.
• All slots not used must be closed by protection caps or dummy plugs in order not to reduce the pro-
tection against accidental contact.
The compact controller is designed for operation of a combination of bowl feeder and linear feeder or bowl
feeder and hopper. Channel 2 can be switched over to belt drive.
The unit offers the following characteristic features:
• Two feed rate outputs
• Channel 1 bowl feeder, linear feeder max. 10A, variable
• Channel 2 linear feeder max. 4A, variable
or AC capacitor motor max. 3A, not variable
• Two sensor amplifiers with independently adjustable timers (On/Off delay).
• External enabling inputs 24 VDC
• Two relay outputs and two optocouplers for status messages and other links.
• Membrane keypad for setting and changing the operating parameters in the set-up menus.
• Plug-type connections for
o vibratory drive / belt drive
o Sensors
o Communication with higher-level controller
• Bipolar main disconnect switch.
The controller is compliant with the following standards:
EC EMC Directive 2014/30/EU
EC Low Voltage Directive
2014/35/EU
The applicable standards are specified in the Declaration of Conformity.
The controller is also available in a UL/CSA compliant version.
