Mains voltage:
230 V AC, 50/60 Hz, +20 / -15%
115 V AC, 50/60 Hz, +10 / -10%
Output voltage:
0 ... 208 V
eff
; (230VAC in motor mode) at 230V supply voltage
0 ... 98V
eff
; (115VAC in motor mode) at 115V supply voltage
Channel 1 load current:
10 A
eff
Channel 2 load current:
4 A
eff
; in motor mode 3A
Total load current:
10 A
eff
Minimum load current:
80 mA
Internal fuse:
F1 = 10A med.time lag/ F2 = 4 med.time lag
Control-circuit fuse
2A med.time lag
Soft start delay, soft stop delay
both channels:
0 ... 5 sec. separately selectable
External setpoint:
0 ... 10V DC
Sensor inputs:
2
2 Enabling inputs:
24V DC (10-24VDC)
Sensor supply:
24V DC, max. 60 mA (per sensor input)
Sensor ON delay:
0 ... 60 sec. separately adjustable
Sensor OFF delay:
0 ... 60 sec. separately adjustable
Outputs:
2 relays (max. 6A 250VAC)
2 floating changeover contacts
2 normally-open contacts carrying supply voltage
Status output:
2 optocouplers, max. 30VDC 10mA,
Ambient temperature:
0 ... 50° C
Cooling:
free convection
Mounting:
vibration-free
Degree of protection:
IP 54
Leakage current
Less than 2mA
Power loss
Tag
Designation
RNA article code
XS1, XS2
Load connector, 5-pin
31002323 (100Hz drives)
XS1, XS2
Load connector, 5-pin
31002322 (50Hz drives)
XS3
Male connector, 5-pole, straight
35051144
XS3
Male connector, 5-pole, right-angled
35002546
XS4
Female connector, 7-pole, straight
35051153
XS4
Female connector, 7-pole, right-angled
35002545
For XS3
Y adapter
39905940
Make sure that following points are checked prior to making connection to power supply and
switching on the controller:
Is the controller casing properly closed with all screws tightened?
Are all plug hooks engaged / firmly screwed in place?
Are all cables and glands in proper condition?
Is operation for the INTENDED USE made sure?
Does the supply voltage specified on the controller match the local supply system?
Does the supply frequency specified on the vibratory drive match the local supply system?
Is the correct mode set on the controller? (See description under "Modes of Operation")
Is sufficient cooling of the controller ensured?
Is the controller mounting vibration-free?
Only if you can clearly answer all the above questions with "Yes" must the controller be put into operation.
