Robe Robin Esprite - Installing the Top hat

10
4.6 Installing the top hat
Disconnect the xture from mains before installing the top hat.
1. Screw the gel frame adaptor [P/N 10980463] (1) on the head (2) by means of the six screws M4x10 (3).
2. Insert the top hat [P/N 10980465] (6) to the gel frame adaptor and secure it by the spring lock (5).
