minutes after last touch (or pressing any button on the control panel).
Touchscreen Lock - The item allows you to lock the screen after last touch (or pressing any button on the
control panel). The time delay can be set in range of 1-10 minutes.To unlock the screen, press the
[ENTER/Display On] button.
Recalibrate Touchscreen - The item starts calibration of the touch screen. Follow the instructions on
the screen.
Display Orientation - The menu allows to change display orientation.
Normal - Standard display orientation if the xture is placed horizontally (e.g. on the ground).
Inverted - Inverted orientation (needed if the xture is hanging on the truss).
Auto - The option activates a gravitation sensor for automatic screen orientation.
Note: Auto option is set as default. You change the display orientation by touching the icon on the display,
an the option set in the "Display Orientation" menu is temporarily overriden.
Temperature unit - Use the menu item to change temperature unit from °C to °F.
Fan Mode - Use the menu to set the xture fans to max. power mode ("High") or to the auto-control mode
("Auto"). The option "Quiet" allows you to set desired fan noise. The light output of the xture
is reduced at low speeds of fans and the High-power Mode is deactivated.
High-power Mode - If the High-power Mode is On, the light output from the xture will be increased about 6%
towards to the operation with fans in High mode. Fans will run on max. power.
Dimmer Curve - Use the menu to select desired dimmer curve: Linear or Square Law.
Date & Time Settings - Use this menu to set current date and time for the xture log system (menu "View
Logs"). Set this menu items before rst xture operation.
Default Settings - The menu item allows to set all xture parameters in this menu to the default (factory) values
except items "DMX Input".
Password Protection - allows to enter password in order to prevent unauthorized person from changing setting
of the xture.
Reset Web Password - The menu item allows you to reset a password for access on the Web server (default
password: 2479, user: robe).
7.4 Tab "Manual Control"
Reset Functions - The menu allows to reset the xture either per function modules or all modules together.
Total System Reset - The item resets all function modules.
Pan/Tilt Reset - The item resets a pan and a tilt.
Colour System Reset - The item resets colour wheel 1/colour wheel 2 and CMY+CTO system.
Gobo/E󰀨. Wh. Reset - The item resets static and rotating gobo wheel and an e󰀨ect wheel.
Optics/Prism/Frost Res. - The item resets a zoom, focus, prism and a frost module.
Iris/Framing Sh. Reset - The item resets an iris module and framing shutters.
Manual E󰀨ect control - Use the menu to control all xture channels by means of the control panel.
7.5 Tab "Stand-alone"
Test Sequences -Use the menu to run a test/demo sequences without an external controller, which will show
you some possibilities of using Robin Esprite.
