DMX protocol
1 2 3 4
Mode/channel
DMX
Value
Function
Type of
control
70-74 Blackout while colour wheels moving: On step
75-79 Blackout while colour wheels moving: Off step
80-84
Fans mode: Auto
step
85-89
Fans mode: High
step
90-94
High-power mode: On
step
95-99
High power mode: Off
step
100-109
Reserved
110-114
Dimmer curve: Square law
step
115-119
Dimmer curve: Linear
step
120-124 Parking position: On step
125-129 Parking position: Off step
To activate following functions, stop in DMX value for at least 3 seconds.
130 - 139 Fixture reset (except pan/tilt)
140 - 149 Pan/Tilt reset step
150 - 159 Colour system reset step
160 - 169 Gobo wheels/effect wheel reset step
170 - 179 Reserved
180 - 189 Zoom/focus/frost/prism reset step
190 - 199 Iris /framing shutters reset step
200 - 209 Total fixture reset step
210-224
Reserved
The following RoboSpot related commands are only applicable when the RoboSpot
is connected:
225 - 229 RoboSpot enabled step
230 - 234 RoboSpot disabled - except handle faders and pan/tilt step
235 - 239 RoboSpot fully disabled step
240 Disabled "Quiet mode" step
241 - 255 Quiet mode - fan noise control from min. to max. proportional
7 7 7 7
Factory display menu setting: 600Hz
Select PWM output frequency of LEDs. Selected PWM frequency can be
fine adjusted in 127 steps up/down around selected PWM frequency on
the channel below. Corresponding menu item (Frequency Setup) is
temporarily overridden.
0-4
PWM frequency from Display menu (fixture utilizes PWM
step
frequency set in the display menu item Frequency Setup).
5-9 300 Hz step
10-14 600 Hz (10=default) step
15-19 1200 Hz step
20-24 2400 Hz step
25-255
Reserved (fixture utilizes PWM frequency set in the display menu item
Frequency Setup).
8 8 8 8
LED frequency fine adjusting
Factory display menu setting: 600Hz
Select desired PWM output frequency of LEDs on the channel above.
0-1 Selected LED Frequency step
2 LED Frequency (step -126) step
3 LED Frequency (step -125) step
4 LED Frequency (step -124) step
