8@~25mmbolt
...
2pcs.
I
lightening torque
11.8
-
13.7 N-m
120
-
140
kgcm
8.7
-
10.1
ft-lb
NOTE
:
When tightening the nuts and bolts, slightly lift the engine and alternator assembly
so
that the
weight is not applied to the mount rubbers
(5)
Attach
the stoppers to
the
frame.
NOTE
1
:
Set the stoppers
so
that the engine base
is placed in the center
of
the upper and
the lower rubbers.
(See
Fig.
10-40.)
NOTE2
:
If
the engine mount rubbers are replaced
with new ones, set the stoppers
so
that
the upper rubber touches the engine
base. The new mount rubber shall be dis-
torted by approx. 3mm in one month.
8
@
x
12
mm
bolt
. .
.4
pcs.
I
lightening toque
I
Make
this
gap
even.
Engine
base
I
II
1
Fig.
70-40
.
~~ ~~ ~~
11.8
-
13.7 N-m
120
-
140
kgcm
8.7
-
10.1
ft-lb
-
45-
