Robotiq inc. © 2008 - 2014 23
Figure 3.5.2.2 : Power connection diagram for the using DeviceNet Fieldbus.3-Finger Gripper
Factory settings for DeviceNet protocol :
Identification Settings
Info Decimal Value ( base 10 ) Hexadecimal Value ( base 16 )
Vendor ID : 283 0x0000011B
Product Code : 35 0x00000023
Serial Number : 0 0x00000000
Product Type : 12 0x0000000C
Major Revision : 1
Minor Revision : 1
Product Name : AG-DNS
