Robotnik SUMMIT XL - 3.3 DC;DC 12 VDC & 5 VDC


RBTNKDOC160609A
SystemElementsandMaintenanceManual
SUMMITXLmobileplatform

3.3DC/DC12VDC&5VDC

There is a 150W 12V DC/DC to provide a stable power supply for the electronic              
elements(PC,Axiscamera,externalpower,…).


Figure1012VDC/DC

There is a small 5V DC/DC which powers the AGVCTRLV2 (optional) and the motor             
drivers.ItislocatedundertheDINrail.


Figure115VDC/DC

 
