Robotnik SUMMIT XL - 3.1 Embedded PC


RBTNKDOC160609A
SystemElementsandMaintenanceManual
SUMMITXLmobileplatform

3.1EmbeddedPC

The main board is a Mitac PD10BI MT with Intel Bay Trail J1900 Quad core processor               
and miniITX form factor. It can be easily replaced by other boards if needed. The              
computer is completed with 4GB of RAM and a 2.5” mSATA HDD mounted on the              
board.


Figure8–PCboard

FormFactor
LowprofileMiniITX(20millimeters[0.79inches]x170.18millimeters[6.7
inches]x170.18millimeters[6.7inches])
Processor
Chipset
IntelBayTrailJ1900Processorwithintegratedgraphics(*Remark:
CompatiblewithJ1800andJ2900)
Memory
● SupportfordualchannelDDR3L1333/1600(runsat1333MHz)
SODIMMs
● Supportforupto8GBofsystemmemoryonasingleSODIMM(or4GB
eachby2SODIMM)
● 204pinDDR3LSODIMM
2
Graphics
● Integratedgraphics:
● Digitaldisplays(HDOut)
● Analogdisplays(VGA)
● Internalflatpaneldisplays:
● LVDS
● EmbeddedDisplayPort*eDP*
● ExternalgraphicssupportviaaPCIExpress1.0ax1graphicsaddincard
connector
11

