RBTNKDOC160609A
SystemElementsandMaintenanceManual
SUMMITXLmobileplatform

Audio
● 2+2ChannelHighDefinitionAudio(HDAudio)usingaRealtek*
ALC888Saudiocodecsupporting:
● Analogstereolineout(backpaneljack)
● Inchassisstereospeakerssupport(3W/3Ωviaaninternalheader)
● S/PDIFdigitalaudiooutput(internalheader)
● DMICdigitalmicrophoneinput(internalheader)
● Analoglinein(backpaneljack)
● FrontpanelHDAudio/AC’97headphones/micsupport(internalheader)
● 8channel(7.1)HDAudioviatheHDOutinterface
Expansion
Capability
● PCIExpress1.0ax1addincardconnectorOption:PCI
Express1.0ax4addincardconnectorby2lanes
1
● PCIExpressFull/HalfMiniCardslot
1
● PCIExpressHalfMiniCardslot
1
Peripheral
Interfaces
● USB2.0frontpanelports
5
● USB3.0backpanelconnectors(blue)
2
● USB2.0highcurrent/fastchargingports(Yellow)
2
● SATA3.0Gb/s
2
● SATA3.0Gb/sport(multiplexedwithanmSATAport,
routedtothePCIExpressFull/HalfMiniCardslot)
1
LegacyI/O
● LegacyI/OController(NCT6683D)thatprovides:
● Hardwaremanagementsupport
● Serialportsonboardheaders
2
● Parallelportviaanonboardheader
1
LANSupport
RealtekRTL8111GCGGigabit(10/100/1000Mb/s)EthernetLANcontroller
includinganRJ45backpanelconnectorwithintegratedstatusLEDs
BIOS
● BIOSresidentinaSerialPeripheralInterface(SPI)Flashdevice
● SupportforAdvancedConfigurationandPowerInterface(ACPI),and
SystemManagementBIOS(SMBIOS)
Hardware
Management
NuvotonNCT6683Dbasedsubsystem,including:
● Voltagesensetodetectoutofrangepowersupplyvoltages
● Thermalsensetodetectoutofrangethermalvalues
12

