RBTNKDOC160609A
SystemElementsandMaintenanceManual
SUMMITXLmobileplatform

● 3pinsystemfanheaderwithspeedcontrol
Power
Requirement
● DCconnectivityviabackpanelDCjack(2.5mm/ID,5.5mm/OD)
● Internal2pinpowerconnector
Environment
● OperatingTemperature:0°Cto+60°C
● StorageTemperature:20°Cto+70°C
Safety
● CE
● FCC
● UL
Table3–MITACPD10BIfeatures
The embedded Linux PC is located in the middle of the robot, under the Edimax              
wirelessrouter.ItsmaintenanceisequivalenttoastandardPCstation.
The main problem can be due to the accumulation of dust in the internal components,              
so it acts as thermal insulator. The heat generated by the components cannot be well              
dissipatedbecauseitistrappedinthedustlayer.
The oil and grease particles contained in the environmental air mix with the dust,             
creating thus a big insulation layer that reflexes the heat to other components. This             
effect causes a reduction of the system useful life. On the other hand, the dust              
contain conductive particles that can generate shortcircuits throughout the circuit         
boardsortheperipheralcards.
The best way to extend the life of the equipment and make it free of reparations for                
manyyearsistocleanitandremovethedustfrequently.

 
