SystemElementsandMaintenanceManual
SUMMITXLmobileplatform

2.4AxisCamera(optional)

Figure6–AxisPTZcamera


CAMERA
AXISP5514PTZDomeNetworkCamera
Imagesensor
1/2.3”progressivescanCMOS
Lens
3.8–42.9mm,F1.4–2.1Horizontalangleofview:59.2°–5.2°
Autofocus,Autoiris
Minimum
illumination
Color:0.7luxat30IREF1.4
B/W:0.08luxat30IREF1.4
Pan/tilt/zoom
Eflip,Autoflip,100presetpositionsPan:360°(withautoflip),
1.8°–100°/sTilt:180°,1.8°–100°/s12xopticalzoom,10xdigital
zoom,total120xzoomLimitedguardtour,Controlqueue
VideoResolution
1280x720to320x180
Compression
H.264(MPEG4Part10/AVC)Baseline,MainandHighProfiles
MotionJPEG
Connectors
RJ4510BASET/100BASETXPoEMulticonnector(cablenot
included)forAC/DCpower,4configurablealarminputs/outputs,
micin,linemonoinput,linemonooutputtoactivespeaker.
Storage
SupportforSD/SDHC/SDXCcard(notincluded)Supportfor
recordingtodedicatednetworkattachedstorage(NAS)
