Robustel M1200 User Guide
RT_UG_M1200_v.1.0.2 9 Apr., 2018 71/78
Select the interface according to the "Ethernet" configuration and select from
"All", "PPP1", "WWAN" and "IO".
Filter the packet that contain the specify IP address.
Set the packet number that the gateway can sniffer at a time.
Select from “All”, “IP”, “TCP”, “UDP” and “ARP”.
Show the current status of sniffer.
Click this button to start the sniffer.
Click this button to stop the sniffer. Once you click this button, a new log file
will be displayed in the following List.
Every times of sniffer log will be saved automatically as a new file. You can find
the file from this Sniffer Traffic Data List and click to download the log, click
to delete the log file. It can cache a maximum of 5 files.
3.24 System > Profile
This section allows you to import or export the configuration file, and restore the gateway to factory default setting.
Import Configuration File
Reset Other Settings to
Default
Click the toggle button as “ON” to return other parameters to default
settings.
