Robustel M1200 User Guide
RT_UG_M1200_v.1.0.2 9 Apr., 2018 17/78
2.5 Attach External Antenna (SMA Type)
Attach an external SMA antenna to the gateway’s antenna connector and twist tightly. Make sure the antenna is
within the correct frequency range provided by the ISP and with 50 Ohm impedance.
Note: Recommended torque for tightening is 0.35 N.m.
2.6 Mount the Gateway
The gateway can be placed on a desktop or mounted to a wall or a 35 mm DIN rail.
Two methods for mounting the gateway
Wall mounting (measured in mm)
