3.8 Interface > DIDO
This section allows you to set the DI and DO parameters. Digital Input and Digital Output are the specific interfaces
for M1200. The DI interface can be used for triggering alarm, while the DO can be used for controlling the slave
device so as to realize real-time monitoring.
DI
Click the right-most button of index 1 as below. The default mode is “ON-OFF”.
The window is displayed as below when choosing “Counter” as the mode.
General Settings @ DI
Item
Description
Default
Index
Indicate the ordinal of the list.
--
Enable
Click the toggle button to enable/disable this DI.
OFF
Mode
Select from “ON-OFF” or “Counter”.
ON-OFF
