Bed Cabinet Components
T x W x L Qty.
A
Inner Frame Strut Piece 3/4" x 1
1
⁄2" x 39
1
⁄2" 10
B
Inner Frame Side 3/4" x 1
1
⁄2" x 75" 2
C
Right Side Rail 3/4" x 5
7
⁄8" x 76
1
⁄2" 1
D
Left Side Rail 3/4" x 5
7
⁄8" x 76
1
⁄2" 1
E
Head Rail 3/4" x 5
7
⁄8" x 41" 1
F
Foot Rail 3/4" x 3" x 41" 1
G
Face Panel 3/4" x 43" x 76
3
⁄4" 1
H
Bed Headboard 3/4" x 15
7
⁄8" x 43
3
⁄8" 1
T x W x L Qty.
I
Bed Cabinet Vertical 3/4" x 15
7
⁄8" x 82
1
⁄8" 2
J
Top Header 3/4" x 14
3
⁄8" x 43
3
⁄8" 1
K
Top Header Front Rail 3/4" x 2
3
⁄4" x 43
3
⁄8" 1
L
Top Header Rear Rail 3/4" x 2
3
⁄4" x 43
3
⁄8" 1
M
Top Header Mounting Cleat 3/4" x 1
1
⁄2" x 14
3
⁄8" 2
N
Mattress Support Panel 1/4" x 41" x 75" 1
O
Leg Support Rail 3/4" x 3/4" x 39
1
⁄4" 1
M
L
A
A
C
B
N
F
O
G
D
I
B
E
H
K
M
J
I
> The Right and Left Side Rails (C
and D) MUST be made with 3/4"
plywood (nominal thickness)
because of the stress placed
on these parts and the need
for greater strength and
structural integrity.
