Rockler Create-A-Bed - Bed Cabinet Parts List

8
Bed Cabinet Parts List
Qty.
11
Male Pivot Plate 2
12
Plastic Pivot Plate Spacer 2
13
E-Clip 2
14
#12 x 3/4" Silver Screw 12
15
Upper Ball Stud Plate 2
16
Ball Stud 2
17
Ball Stud Spacer 2
18
Gas Spring 2
19
Bed Stop 2
20
Mattress Retaining Strap 2
Qty.
1
Right Metal Pivoting Leg 1
2
Left Metal Pivoting Leg 1
3
#10 x 3/4" Black Screw 6
4
T-Nut 16
5
Machine Screw 16
6
1/4" x 2" Hex-drive Leg
Support Rail Screw
2
7
Right Lower Ball Stud Plate 1
8
Left Lower Ball Stud Plate 1
9
#10 x 1
5
⁄8" Screw 4
10
Female Pivot Plate 2
2
8
19
12
13
11
10
9
6
16
17
15
18
