Rockwell Automation Publication 2198-UM005C-EN-P - February 2022 103
Chapter 6 Configure and Start up the Kinetix 5300 Drive System
Change the DHCP Setting
DHCP is enabled by default, follow these steps to disable DHCP.
1. From the Home screen, press Next to access the main menu.
2. Press Next to scroll through the sub-menu until DHCP is displayed.
3. Press Select to choose the DHCP sub-menu.
4. Press Next to scroll through the DHCP sub-menu.
5. Press Select to choose ON or OFF.
6. When ACCEPT is displayed, press Select to accept the modification and
return to the DHCP menu.
Change the IP Settings
Follow these steps to update the network settings.
1. From Home Screen, press Next to access the main menu.
2. Press Next to scroll through the main menu until IP SETTINGS is
displayed.
3. Press Select to choose IP SETTINGS.
4. Within the IP SETTINGS menu, press Next to navigate the sub-menu: IP
ADDRESS, SUBNET, or GATE.
5. Press Select to choose the desired network setting.
Within the setting, if the character is editable, the character blinks.
a. Press Select to increment the active character to the desired number.
b. Press Next to move to the next character.
c. Press Back t0 move to the previous character.
6. After modifying the last character, press Next.
The display now shows ACCEPT.
7. Press Select to accept the modification and return to the IP SETTINGS
sub-menu.
8. Press Back to validate the configured network settings.
9. Cycle 24V power to apply the network setting changes.
The active selection is displayed with dashes surrounding On or Off (-ON-, for
example).
Cycle 24V power for changes to take effect.
If necessary, update all network settings by repeating step 4…step 7 before
validating the changes.
IMPORTANT Net Err is displayed if any of the network settings are incompatible (or
Protected Net is set to ON). Review your network settings and make sure
they are compatible (or Protected Net is set to OFF). The IP and Gateway
addresses must be on the same Subnet.
