Rockwell Automation Publication 2198-UM005C-EN-P - February 2022 193
Appendix B Upgrade Kinetix 5300 Drive Firmware
3. Select your Kinetix 5300 drive.
In this example, the 2198-C4075-ERS drive is selected.
4. Click Next.
The Select Device to Update dialog box appears.
5. Expand your Ethernet node, Logix backplane, and EtherNet/IP network
module.
6. Select the Kinetix 5300 drive to upgrade.
7. Click OK.
The Firmware Revision dialog box appears.
8. Select the firmware revision to upgrade.
9. Click Next.
The Summary dialog box appears.
If your catalog number does not appear, click Browse, select the monitored
folder where the firmware kit (DMK files) is located. Click Add and OK.
