Publication 2711C-UM001C-EN-P - September 2009 67
Cable Connections and Communication Chapter 4
Configure the Terminal for USB Connection
Follow these steps to configure your terminal to be connected
through a USB port to a computer.
1. Connect the USB host port on the computer to the USB device
port on the terminal.
2. Power-up the terminal.
When the terminal connects to the computer for the first time,
the new USB device (the PanelView Component terminal) is
discovered by the Windows Found New Hardware Wizard that
guides you through the installation.
There are two instances of the driver. There is one for the Boot
Loader and one for the Windows CE Operating System. The USB
IP address is always 169.254.254.2.
IMPORTANT
The terminal should be directly connected to a USB port on
the computer. Do not connect through some other device,
such as a USB port on a monitor, keyboard, or laptop
computer docking station.
