168 Rockwell Automation Publication 5094-UM001E-EN-P - April 2020
Appendix B Module Tag Definitions
5094-OB8 Module Tags
This section describes the tags that are associated with the 5094-OB8 module.
Configuration Tags
Tab le 52 describes the 5094-OB8 module configuration tags.
Input Tags
Tab le 53 describes the 5094-OB8 module input tags.
STATUS
POWER
DIGITAL 16 INPUT 24 VDC
5094-IB16
1
1
TB3
FLEX 5000
TM
I/O
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Table 52 - 5094-OB8 Module Configuration Tags
Name Data Type Definition Valid Values
Ptxx.FaultMode BOOL Selects the behavior the output point takes if a
communication fault occurs. FaultValue defines the value to
go to when set to user-defined value.
• 0 = Go to a user-defined value
• 1 = Hold last state
Ptxx.FaultValue BOOL Defines the value that the discrete output should assume if a
communication fault occurs when FaultMode = 0.
•0 = Off
•1 = On
Ptxx.ProgMode BOOL Selects the behavior the output point should take when
transitioned into Program mode. ProgValue defines the
value to go to when set to user-defined value.
• 0 = Go to a user-defined value
• 1 = Hold last state
Ptxx.ProgValue BOOL Defines the value that the output should take when the
connection transitions to Program mode if the ProgMode bit
is set to "User-Defined Value".
• 0 = The output state is Off during Program mode.
• 1 = The output state is On during Program mode.
Ptxx.FaultFinalState BOOL If FaultValueStateDuration is nonzero determines the final
Output state after the configured FaultValueStateDuration
time out occurs.
• 0 = The output state is Off after the
FaultValueStateDuration time expires.
• 1 = The output state is On after the
FaultValueStateDuration time expires.
Ptxx.ProgramToFaultEn BOOL Determines if an output should transition to the Fault Mode
if the connection faults while in Program Mode.
• 0 = Stay in Program Mode
• 1 = Go to Fault mode
Ptxx.NoLoadEn BOOL Enables no load detection for output points. • 0 = Disable
•1 = Enable
Ptxx.FaultValueStateDuration SINT This value determines the length of time the Fault Mode
state is held before the FaultFinalState being applied.
•0 = Hold forever (default).
• 1, 2, 5, or 10 seconds
Table 53 - 5094-OB8 Module Input Tags
Name Data Type Definition Valid Values
RunMode BOOL The point’s operating state • 0 = Idle
•1 = Run Mode
ConnectionFaulted BOOL Indicates if a connection is running.
The module sets this tag to 0 when connected. If the module
is not connected, it changes the tag to 1.
• 0 = Connection running
• 1 = Connection not running
DiagnosticActive BOOL Indicates if any diagnostics are active or if the prognostics
threshold is reached.
• 0 = No diagnostics active
• 1 = One or more diagnostics are active or the
prognostics threshold is reached
Uncertain BOOL Indicates if the module is operating outside is designed
operating range of if data is under manual or override
control.
• 0 = Good
• 1 = Uncertain
