Rockwell Automation Publication 1769-IN088A-EN-P - February 2011 103
I/O Memory Mapping Chapter 3
Data Format
Raw/
Proportional
000
Engineering
Units
001
Engineering
Units X 10
100
Scaled-for-
PID
010
Percent
Range
011
Enable
Channe
Enable 1
Disable 0
To Select Make these bit settings
1514131211109876543210
