Rockwell Automation Publication 1769-IN088A-EN-P - February 2011 161
I/O Memory Mapping Chapter 3
Output Data
Local:1:O AB:1769_OF8V:O:0
+ Local:1:O.Ch0Data INT Decimal
+ Local:1:O.Ch1Data INT Decimal
+ Local:1:O.Ch2Data INT Decimal
+ Local:1:O.Ch3Data INT Decimal
+ Local:1:O.Ch4Data INT Decimal
+ Local:1:O.Ch5Data INT Decimal
+ Local:1:O.Ch6Data INT Decimal
+ Local:1:O.Ch7Data INT Decimal
+ Local:1:O.AlarmUnlatch INT Binary
Local:1:O.Ch0OverRangeUnlatch BOOL Decimal
Local:1:O.Ch0UnderRangeUnlatch BOOL Decimal
Local:1:O.Ch1OverRangeUnlatch BOOL Decimal
Local:1:O.Ch1UnderRangeUnlatch BOOL Decimal
Local:1:O.Ch2OverRangeUnlatch BOOL Decimal
Local:1:O.Ch2UnderRangeUnlatch BOOL Decimal
Local:1:O.Ch3OverRangeUnlatch BOOL Decimal
Local:1:O.Ch3UnderRangeUnlatch BOOL Decimal
Local:1:O.Ch4OverRangeUnlatch BOOL Decimal
Local:1:O.Ch4UnderRangeUnlatch BOOL Decimal
Local:1:O.Ch5OverRangeUnlatch BOOL Decimal
Local:1:O.Ch5UnderRangeUnlatch BOOL Decimal
Local:1:O.Ch6OverRangeUnlatch BOOL Decimal
Local:1:O.Ch6UnderRangeUnlatch BOOL Decimal
Local:1:O.Ch7OverRangeUnlatch BOOL Decimal
Local:1:O.Ch7UnderRangeUnlatch BOOL Decimal
