Chapter 3 I/O Memory Mapping
1769-IM12
The following I/O memory mapping lets you configure the 1769-IM12 module.
Input Data File
For each input module, slot x, word 0 in the input data file contains the current
state of the field input points. For the 1769-IM12, bits 12 to 15 are not used.
1769-IQ16
The following I/O memory mapping lets you configure the 1769-IQ16 module.
Input Data File
For each input module, slot x, word 0 in the input data file contains the current
state of the field input points.
Word
Bit Position
1514131211109876543210
0
0 0 0 0r
(1)
(1) r = read.
rrrrrrrrrrr
Word
Bit Position
1514131211109876543210
0r
(1)
(1) r = read.
rrrrrrrrrrrrrrr
