104 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 3 I/O Memory Mapping
Module Configuration Word
Word 6 of the configuration data file contains the Enable/Disable Cyclic
Calibration bit as shown in the table below.
1769-IT6
The following I/O memory mapping lets you configure the 1769-IT6 module.
Input Data File
The input data file contains the analog values of the inputs.
The bits are defined as follows:
Sx = General status bit for channels 0…5 and CJC sensors (S6 and S7).
This bit is set (1) when an error (over-range, under-range, open-circuit, or
input data not valid) exists for that channel. An ‘input data not valid’
condition is determined by the user program. This condition occurs when
the first analog-to-digital conversion is still in progress, and after a new
configuration has been sent to the module. Refer to the Compact I/O
Thermocouple/mV Input Module User Manual, publication 1769-
UM004 for additional details.
To Select Make these bit settings
1514131211109876543210
Enable/
Disable
Cyclic
Calibration
Enabled
(1)
(1) When enabled, an autocalibration cycle is performed on all enabled channels every 5 minutes.
0
Disabled
1
Word
Bit Position
15 14131211109876543210
0 Analog Input Data Channel 0
1 Analog Input Data Channel 1
2 Analog Input Data Channel 2
3 Analog Input Data Channel 3
4 Analog Input Data Channel 4
5 Analog Input Data Channel 5
6OC7 OC
6
OC
5
OC
4
OC
3
OC
2
OC
1
OC
0
S7 S6 S5 S4 S3 S2 S1 S0
7 U0 O0U1U0U2O2U3O3U4O4U5O5U6O6U7O7
