150 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 3 I/O Memory Mapping
Local:1:I.Ch3InHold BOOL Decimal
Local:1:I.Ch3OpenWire BOOL Decimal
+ Local:1:I.Ch4_5Status SINT Binary
Local:1:I.Ch4OverRange BOOL Decimal
Local:1:I.Ch4UnderRange BOOL Decimal
Local:1:I.Ch4InHold BOOL Decimal
Local:1:I.Ch4OpenWire BOOL Decimal
Local:1:I.Ch5OverRange BOOL Decimal
Local:1:I.Ch5UnderRange BOOL Decimal
Local:1:I.Ch5InHold BOOL Decimal
Local:1:I.Ch5OpenWire BOOL Decimal
+ Local:1:I.Ch6_7Status SINT Binary
Local:1:I.Ch6OverRange BOOL Decimal
Local:1:I.Ch6UnderRange BOOL Decimal
Local:1:I.Ch6InHold BOOL Decimal
Local:1:I.Ch6OpenWire BOOL Decimal
Local:1:I.Ch7OverRange BOOL Decimal
Local:1:I.Ch7UnderRange BOOL Decimal
Local:1:I.Ch7InHold BOOL Decimal
Local:1:I.Ch7OpenWire BOOL Decimal
+ Local:1:I.Ch0ReadBack INT Decimal
+ Local:1:I.Ch1ReadBack INT Decimal
+ Local:1:I.Ch2ReadBack INT Decimal
+ Local:1:I.Ch3ReadBack INT Decimal
+ Local:1:I.Ch4ReadBack INT Decimal
+ Local:1:I.Ch5ReadBack INT Decimal
+ Local:1:I.Ch6ReadBack INT Decimal
+ Local:1:I.Ch7ReadBack INT Decimal
Tag
Name
Bit Indicates This
(1)
76543210
Combined
Status
Ch7
Status
Ch6
Status
Ch5
Status
Ch4
Status
Ch3
Status
Ch2
Status
Ch1
Status
Ch0
Status
Module
Status
Power
Fail
Ch0_1
Status
Ch1
OpenWire
Ch1
InHold
Ch1
Under
Range
Ch1 Over
Range
Ch0
OpenWire
Ch0
InHold
Ch0
Under
Range
Ch0
Over
Range
- Local:1:I AB:1769_OF8C:I:0
