B-8 HIM Overview
The HIM can be removed or installed while the drive is powered.
Important: HIM removal is only permissible in Auto mode. If the HIM
is removed while in Manual mode or the HIM is the only
remaining control device, a fault will occur.
Removing/Installing the HIM
Step Key(s) Example Displays
To remove the HIM . . .
1. Press ALT and then Enter (Remove). The
Remove HIM confirmation screen appears.
2. Press Enter to confirm that you want to
remove the HIM.
3. Remove the HIM from the drive.
To install HIM . . .
1. Insert into drive or connect cable.
ALT
+
Remove Op Intrfc:
Press Enter to
Disconnect Op Intrfc?
(Port 1 Control)
20B-UM001.book Page 8 Thursday, June 20, 2013 1:55 PM
